MYOGRAPH

STUDIES ON TISSUE
PULMONARY STUDIES

TARGET OF THE PROJECT

To create gas mixtures for measuring the airway and artery in lung’s physiologic features.

Description of the Application.

Case Western Reserve University uses the gas mixer to changing O2 concentration to measure the airway and artery in lung’s physiologic features, including the response to different level of O2 and medicines. Hence, to understand the regulation of contraction and relaxation of the tissue.

MYOGRAPH - GAS MIXTURES

Gas Mixer VS Gas Cylinder

The ability to blend O2 simulations on-demand is an incredibly powerful tool in the development and provides a level of flexibility that gas cylinders cannot provide.

Flexibility

By using the MCQ gas blender it is possible to set up different concentrations of O2, to adjust to whatever combination they want.

High Accuracy - Low Rate

Thanks to our revolutionary method without the Cut-Off, every gas flow has an high accuracy making possible to have a stable flow also for lower flow-range.

Micro Flow Rates

Our GB100 Series allows the Case Western Reserve University to control the flow in all the calibration range, from 0,1 ml/min to 500 ml/min with NO cut-off.

Easy to Use - Software

Thanks to our Software PRO Version and its easy-to-use user interface, now the Case Western Reserve University can easy set all the experiment through our software.

Successful Achievement

The MCQ gas blender is used to adjust the O2 concentration to understand the regulation of contraction and relaxation of the tissue.

Company Info:

Case Western Reserve University (CWRU) is a private research university in Cleveland, Ohio. It was created in 1967 through the federation of two longstanding contiguous institutions: Western Reserve University, founded in 1826 and named for its location in the Connecticut Western Reserve, and Case Institute of Technology, founded in 1880 through the endowment of Leonard Case, Jr. Time magazine described the merger as the creation of “Cleveland’s Big-Leaguer” university.

(Ref: Wikipedia)
